USG-2 NMEA 0183 USB Converter USB to Serial Gateway

The USG-2 ensures safety and reliability when connecting a PC to your NMEA 0183 network.

The USG-2 converts a USB port into a bi-directional serial port suitable for connecting to a marine standard NMEA 0183 data bus.

Where To Buy

USG-2 USB to Serial Gateway

USG-2 USB to Serial Gateway

USG-2 USB to Serial Gateway

It provides a far safer connection when compared to standard USB to serial converters.

Electrical isolation is provided by the ISO-Drive™ output and OPTO-isolated input making installation simple and free from ground loops.

The input uses the Actisense OPTO-isolation circuitry to protect any connected equipment from the most common system faults. The input can receive very low-level signals that are often too small to be received by a PC serial port.

The USG-2 is the safest way to connect a boat’s data network to an on-board PC.

Ordering Information

(Part number/s)

  • USG-2

Note: The USG-2 ships with a USB cable included in the box. However, the USG-2 cable is also available as an accessory in case a replacement is needed.



FEATURES

  • NMEA 0183, RS422 & RS232 compatible
  • ISO-Drive™ technology
  • Pluggable screwless connector with locking latch & strain relief
  • Encapsulated electronics
  • High retention USB socket
  • Diagnostic & power LEDs
  • Baud rates from 300 to 230400 bps
  • Bulkhead mount, with optional DIN rail mount kit
  • Pluggable screwless connector


BENEFITS

  • Inputs & outputs protected against over voltage, ESD & short circuits
  • Simple installation
  • Protects PC from damage
  • Eliminates ground loops
Supply voltage835V
Supply currentSupply voltage 12v (Min. load, Max. load)670mA
Supply voltage 24v (Min. load, Max. load)4.840mA


NMEA in





Input voltage toleranceContinuous operation-1515V
Short Term Operation (<1 sec)-3535V
Differential input voltageRequired level for data to be detected1.8V
Intput current2mA
Input to output protection



Full Galvanic Opto-isolation protection





2000



V



RS485/RS422 outNMEA 0183 version 2-3
Output currentRS485/RS422 compatible1540mA
Differential output voltage



50 ohm load



2





V



RS232 outNMEA 0183 version 1-3 & PC serial
Output current510mA
Output voltage



 3k ohm load



+/-5





V



General
Baud rate57600bps
Ambient temperature-2070°C
  • No firmware which means no configuration needed
  • Isolated inputs and outputs protect PC from damage
  • Compatible with all NMEA 0183 devices
  • Encapsulated electronics make the USG-2 robust for the harsh marine environment
  • High retention USB socket
  • Diagnostic LEDs to aid diagnosis
  • Baud rates from 300 to 230400 bps suit all NMEA 0183 networking bandwidths
  • Bulkhead mount, with optional DIN rail mount kit for quick and easy installation
  • Pluggable screwless connector with locking latch & strain relief



NETWORK DIAGRAM

Here are some Frequently Asked Questions about the USG-2.

Need more help? Visit our Support Centre or Contact Us.
