USG-1 USB TO NMEA

The USG-1 is no longer in production. Opt for the USG-2 instead.

Connect your boat’s data network to your PC with the safety of full electrical isolation.

The Actisense USG-1 is the safest way to connect a boat’s data network to an on-board PC. It converts a USB port into a bi-directional serial port suitable for connecting to a marine standard NMEA 0183 data bus.

Actisense retired product 750x750 1 1

The ISO-Drive output and OPTO input provide full isolation, making installation simple and free from ground loops.

The OPTO input uses the Actisense isolation circuitry to protect any connected equipment from most common system faults. The isolator can receive very low level differential signals that are often too small to be received by a PC serial port.

The USG-1 overcomes all the problems of using a low-cost USB to RS232 cable from a computer store (when handshaking is not required). It eliminates the risk of damage to the PC as it provides complete isolation.

  • Create a serial port connection to an NMEA 0183 system, that may be on a different power circuit from the PC
  • Connect two PCs together that are on different power circuits
  • Provide a compliant NMEA 0183 port from a USB port
  • Receive low level differential signals that are too small to be received by a PC serial port
  • Free up PC serial/COM port for other uses
Supply voltage From USB port 4.75 5.25 V
Supply current (drawn from USB port)



Supply voltage 5v (no load)

Supply voltage 5v (output shorted)



40

75



46

80



mA

mA



Opto-isloated in NMEA 0183 version 1-3 & PC Serial
Input voltage tolerance Continuous operation

Short term operation (< 1 sec)

-15

-35

+15

+35

V

V

Differential input voltage Required level for data to be detected 1.8 2.0 V
Input current 20 9.0 mA
Galvanic isolation Between input & output 2500 V
Overdrive protection









40



V



ISO-DRIVE Flexible out NMEA 0183 version 1-3 & PC Serial
Differential output voltage Continuous operation

Max. 100 ohm load

-5.2

2.1

+5.2

V

V

Output current (Max) Max. 100 ohm load 21 mA
Output current (Short) Due to short circuit protection 50 55 mA
Galvanic isolation Between Opto-input and (USB ground) 1500 V
Static discharge protected









15000



V



PC Comm settings
Baud rate



Set in PC software Comm port settings



300



115200



bps



General
Ambient temperature -20 +70 °C
Guarantee Actisense guarantee  3 Years
